Top Feed Vibroflot with 180 KW and 260 KW Motor Power and 2320kg Weight for Vibro Compaction

Top Feed Vibroflot with 180 KW and 260 KW Motor Power and 2320kg Weight for Vibro Compaction

180 KW Motor Power Top Feed Vibroflot,260 KW Motor Power Vibroflotation Equipment,2320kg Weight Vibro Compaction Machine

260 KW Motor Power Vibroflotation Equipment

2320kg Weight Vibro Compaction Machine

محل منبع:

چین

نام تجاری:

BVEM

گواهی:

CE、ISO 9001:2000、ISO 9001:2008

شماره مدل:

BJVE 426-180، BJVE 450-260

با ما تماس بگیرید

درخواست نقل قول
جزئیات محصول
وضعیت::
جدید
قدرت موتور::
180 کیلووات، 260 کیلووات
وزن::
2320 کیلوگرم، 3280 کیلوگرم
ابعاد (L*W*H)::
3020*676*440mm، 3310*700*450mm
برنامه::
فشرده سازی ویبرو، جایگزینی ویبرو
موتور::
300Kw/400Kw
نوع برق::
برقی
حداکثر دامنه::
22 میلی متر، 26 میلی متر
Max. حداکثر Speed: سرعت::
1450 دور در دقیقه
نیروی گریز از مرکز::
280kN,440 KN
گارانتی::
1 سال یا 2000 ساعت (هر چیزی که اول اتفاق بیفتد)
شرایط پرداخت و حمل و نقل
مقدار حداقل تعداد سفارش
1 مجموعه
جزئیات بسته بندی
کیس چوبی
زمان تحویل
20-35 روز
شرایط پرداخت
L/C، T/T
قابلیت ارائه
600 مجموعه در سال
محصولات مرتبط
با ما تماس بگیرید
86-010-69592173
اکنون تماس بگیرید
توضیحات محصول
Top Feed Vibroflot with High Centrifugal Force Adjustable Speed and Large Amplitude for Vibro Compaction
Comparative Analysis of Vibroflotation Equipment Series
In the field of vibroflotation equipment, different technical types and models exhibit significant differences in performance parameters and application scenarios. This analysis compares four vibroflotation equipment models to provide professional references for equipment selection decisions.
Main Parameter Comparison
Vibro Model BJVE-426-180 (Electric Normal) BJVE-450-260 (Electric Normal) BJVH-350-150 (Hydraulic) BJVEF-450-225 (Electric Frequency Conversion)
Diameter (mm) 426 450 350 450
Power (kW) 180 260 150 225
Speed (rpm) 1450 1450 2600-2900 1450-1740
Centrifugal Force (kN) 280 440 250-350 520
Max. Amplitude (mm) 22 26 11 20
Comparison of Core Parameters: From Specifications to Power Performance
Differences in Basic Specifications
Diameter: Ranges from 350mm (BJVH-350-150) to 450mm (BJVE-450-260 and BJVEF-450-225), with the BJVE-426-180 measuring 426mm. Larger-diameter equipment offers wider vibration influence range while smaller-diameter models provide stronger penetration and greater flexibility.
Power: Ranges from 150kW (BJVH-350-150) to 260kW (BJVE-450-260). Power determines the equipment's vibration output capacity and continuous operating intensity.
Power and Vibration Performance
Speed: Conventional electric models operate at fixed 1450rpm, while the electric variable-frequency model features adjustable speed (1450-1740rpm). The hydraulic model has a wide speed range (2600-2900rpm) for complex hard soil layers.
Centrifugal Force: The BJVEF-450-225 leads with 520kN, followed by BJVE-450-260 (440kN), BJVH-350-150 (250-350kN range), and BJVE-426-180 (280kN). High centrifugal force enables efficient handling of high-resistance vibration operations.
Maximum Amplitude: The BJVE-450-260 has the largest amplitude at 26mm. Equipment with large amplitude provides greater influence on soil compaction around the vibration area.
