Name: Hydraulic Vibroflot with 1700 Kg Weight 220 Kn Max. Centrifugal Force and 0-2600 r/min Max. Speed for Excavator Vibro Compaction
Brand: Beijing Vibroflotation Engineering Machinery Limited Company
SKU: BJVH-350-150
Price: 26,000.00 USD
Availability: InStock

صفحه اصلی > محصولات > وایبروفلوت هیدرولیک >

Hydraulic Vibroflot with 1700 Kg Weight 220 Kn Max. Centrifugal Force and 0-2600 r/min Max. Speed for Excavator Vibro Compaction

1700 Kg Weight Hydraulic Vibroflot,220 Kn Max. Centrifugal Force Vibroflotation Equipment,0-2600 r/min Max. Speed Excavator Vibro Compaction

220 Kn Max. Centrifugal Force Vibroflotation Equipment

0-2600 r/min Max. Speed Excavator Vibro Compaction

محل منبع:

چین

نام تجاری:

BVEM

گواهی:

CE、ISO 9001:2000、ISO 9001:2008

شماره مدل:

BJVH-350-150

مدرک:

BVEM-Hydraulic Vibroflot & ...or.pdf

با ما تماس بگیرید

درخواست نقل قول

جزئیات محصول

نوع قدرت:

هیدرولیک

وزن:

1700 کیلوگرم

ابعاد (L*W*H):

2250*650*340 میلی متر

گارانتی:

1 سال یا 2000 ساعت

برنامه:

تراکم، ستون سنگی

دستگاه تنظیم برق:

176 کیلو وات

وضعیت:

جدید

قدرت:

150 کیلو وات

Max. حداکثر centrifugal force نیروی گریز از مرکز:

220 کیلونیوتن

حداکثر سرعت:

0-2600 دور در دقیقه

شرایط پرداخت و حمل و نقل

مقدار حداقل تعداد سفارش

1 مجموعه

جزئیات بسته بندی

کیس چوبی

زمان تحویل

30-45 روز

شرایط پرداخت

L/C، T/T

قابلیت ارائه

600 مجموعه / سال

محصولات مرتبط

با ما تماس بگیرید

86--13581545619

tianss@bjvibro.com

86-010-69592173

اکنون تماس بگیرید

توضیحات محصول

Hydraulic Vibroflot with 1700 Kg Weight 220 Kn Max. Centrifugal Force and 0-2600 r/min Max. Speed for Excavator Vibro Compaction

Product Description

Hydraulic Vibrator with Excavator Vibro Compaction

About Vibroflotation

Vibroflotation utilizes high-pressure water or air to generate horizontal vibrations from vibroflot equipment, compacting loose foundations. The process involves boring holes in soil layers and filling them with hard coarse materials to form reinforcement bodies that create composite foundations with surrounding soil.

Technical Specifications

Brand	Japan brand 360-10
Power	210 kW
Lifting Height	8.2m
Lifting Weight	5T
Hydraulic Vibrator	BJVH-350-150
Pile Spacing	2m
Depth	6.5m

Key Advantages

Complete machine construction
Convenient construction process
Shares excavator hydraulic power
Easy transformation capability

Applications

Dry city construction (suitable for sand gravel layers)
Small outside diameter (700-1000mm)
High modification potential (compatible with rotary drilling rigs and excavators)

Key Characteristics

Simple, convenient and economical equipment and materials
Ideal for foundation treatment projects including:
- Hydropower stations
- Petrochemical plants
- Port terminals
- Dams
- Airport runways
Improves bearing capacity and prevents uneven soil settlement
Enhances anti-liquefaction ability of foundation interlayers

Drawings & Dimensions

Detailed CAD drawings and dimensional diagrams are available for download or upon inquiry. Our engineering team can provide tailored designs to meet specific project requirements.

After Sales Service

Standard Warranty: 12 months or 2,000 operating hours (whichever comes first)
Global Support: 24/7 technical assistance and spare parts supply
Training: On-site or remote operation/maintenance training

About Beijing Vibroflotation Engineering Machinery Co. Ltd (BVEM)

BVEM is a subsidiary of Powerchina Vibro-flotation Construction Engineering Co., Ltd., a leader in China's vibroflotation industry. As the domestic leader in complete vibroflot equipment development and production, BVEM operates the largest domestic production line of electric vibroflots. The company serves as the chief-editor of the Chinese electric vibroflot manufacturing standard and provides high-quality complete vibroflot equipment solutions worldwide.

Why Choose BVEM?

OEM/ODM capabilities
Competitive pricing & bulk discounts
Fast shipping & customs clearance support
Comprehensive project solutions including:
- Geological analysis
- Vibroflotation design
- Equipment selection
- Construction scheme
- Installation commissioning
- Construction guiding

Other Products

Top Feed Vibroflot
Hydraulic Vibroflot
Multi point vibro-compaction
Multi functional pile frame
Excavator Vibroflot
